HUAWEI Mate 20

General

- Model: Huawei Mate 20

- Announced / Released: October 2018 / November 2018 (discontinued)

- Dimensions / Weight: 158.2 × 77.2 × 8.3 mm / 188 g

- Build: Aluminium frame, Gorilla-Glass front & back

- Protection: IP53 (dust / vertical-spray water)

- SIM: Single or Dual-Nano (dual-stand-by)

Display

- Size & Type: 6.53-inch IPS LCD, HDR10

- Resolution: 1080 × 2244 px (18.7 : 9), 381 ppi

- Screen-to-body: ≈ 88 %

Platform

- OS: Android 9.0 (Pie) + EMUI 9.1

- Chipset: HiSilicon Kirin 980 (7 nm)

- CPU: Octa-core (2×2.6 GHz Cortex-A76 + 2×1.92 GHz A76 + 4×1.8 GHz A55)

- GPU: Mali-G76 MP10

Memory & Storage

- RAM / ROM variants: 4 GB / 64 GB – 6 GB / 128 GB (UFS 2.1)

- Expansion: Huawei Nano Memory (uses shared SIM slot, up to 256 GB)

Rear Cameras – Triple (Leica optics)

1. 12 MP 27 mm wide, f/1.8, 1/2.3", PDAF

2. 8 MP 54 mm telephoto, f/2.4, 2× optical zoom, PDAF

3. 16 MP 17 mm ultra-wide, f/2.2

- Focus: Laser AF

- Flash: Dual-tone LED

- Video rear: 4K@30 fps, 1080p@30/60 fps, 720p@960 fps, gyro-EIS

Front Camera

- 24 MP wide, f/2.0, 1/2.8", fixed-focus

- Video front: 1080p@30 fps

Battery & Charging

- Capacity: 4 000 mAh Li-Po, non-removable

- Wired charge: Huawei SuperCharge 22.5 W (58 % in 30 min)

Communications

- 2G / 3G / LTE Cat-21 (1 400 / 200 Mbps)

- Wi-Fi: 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA

- Bluetooth 5.0: aptX HD, LE

- Positioning: GPS (L1+L5), GLONASS (L1), BDS (B1), Galileo (E1+E5a), QZSS (L1+L5)

- NFC: Yes

- Infrared blaster: Yes

- Radio: FM radio

- USB-C 3.1: OTG

Audio & Sensors

- Stereo speakers (bottom + ear-piece)

- 3.5 mm headphone jack: Yes

- 32-bit / 384 kHz Hi-Res audio

- Sensors: Rear-mounted fingerprint, accelerometer, gyro, proximity, barometer, compass, Hall
