CTZX50

Benchtop Mill/Drill with Power Feed and Tapping

It is suitable for drilling, reaming and hole machining

on metal materials and other materials. It can also be

used for face milling and end milling and tapping

screw holes.

The spindle automatic feed is driven by an

independent motor, the feed speed is controlled by

stepless speed regulation, the tapping is

automatically reversed, and the spindle handle is

equipped with a positive and negative button.

900x260mm T-slot table, lateral automatic feed,

improve milling accuracy.

All-metal gear drive, variable speed range is wide

and suitable.

Table and column adopts dovetail guide rail with

sufficient stiffness and stability.

Three-axis grating digital display, easy to observe or

track the feed stroke, greatly improve the machining

accuracy.

Independent cooling system, water pump motor

0.09KW,25L/min.

Heavy floor tank, greater bearing capacity, drilling

and milling operation is more stable.
