1. Use imported SKF bearings to improve service life and accuracy.

2.750W main motor, belt drive.

3. The middle slide plate is equipped with a T-shaped slot to hold

the workpiece and can be used as a milling machine workbench.

4. The middle slide plate adopts dovetail guide rail. The guide rail

gap can be adjusted according to the taper insert. It is

wear-resistant, surface contact and has good rigidity.

5. Push-pull clutch device can switch between turning or drilling

and milling operations.

6. Follow CE and ISO production system standards, safe and

reliable.

7. A multifunctional machine tool suitable for home use,

maintenance workshops, and laboratories.

TURNING

1. The spindle has 6 levels of rotational speed, ranging from 160 to

1600rpm.

2.It can turn inch and metric threads and automatically feed

vertically and horizontally.

MILLING

1. Milling spindle speed, speed range 125~1600rpm.

2. The spindle can be fed in two ways: rapid feed and micro feed.

3. The milling head can be raised, lowered or rotated 360°.
