CT300

1. Use imported SKF bearings to improve service life and accuracy.

2. 750W main motor, belt drive.

3. The middle slide plate is equipped with a T-shaped slot to hold

the workpiece and can be used as a milling machine workbench.

4. The middle slide plate adopts dovetail guide rail. The guide rail

gap can be adjusted according to the taper insert. It is

wear-resistant, surface contact and has good rigidity.

5. Push-pull clutch device can switch between turning or drilling

and milling operations.

6. Follow CE and ISO production system standards, safe and

reliable.

7. A multifunctional machine tool suitable for home use,

maintenance workshops, and laboratories.

TURNING

1.The spindle has 6 levels of rotational speed, ranging from 160 to

1600rpm.

2. It can turn inch and metric threads and automatically feed

vertically and horizontally.

MILLING

1. Milling with 12 levels of speed, speed range 125~1600rpm.

2. The spindle can be fed in two ways: rapid feed and micro feed.

3. The milling head can be raised, lowered or rotated 360°.
